| TYPICAL PARAMETERS: |
| Single Layer | ||||||
| ZTT Standard | Fiber Count(Max) | Diameter (mm) | Weight (Kg /Km) | RTS (KN) | Short Circuit (KA s) | |
| OPGW-78 [78.7,37.6] | 24 | 11.6 | 498 | 78.7 | 37.6 | |
| OPGW-77 [63.6,41.6] | 28 | 11.6 | 451 | 63.6 | 41.6 | |
| OPGW-77 [78.6,36.2] | 28 | 11.6 | 496 | 78.6 | 36.2 | |
| OPGW-111 [58.9,103.7] | 48 | 13.8 | 511 | 58.9 | 103.7 | |
| OPGW-187 [75.3,308.2] | 48 | 18.0 | 679 | 75.3 | 308.2 | |
| OPGW-81 [63.2,46.7] | 48 | 11.9 | 458 | 63.2 | 46.4 | |
| OPGW-74 [68.5,36.4] | 60 | 11.4 | 444 | 68.5 | 36.4 | |
| OPGW-84 [42.4,59.9] | 60 | 12.1 | 383 | 42.4 | 59.9 | |
| Double Layers | ||||||
| ZTT Standard | Fiber Count(Max) | Diameter (mm) | Weight (Kg /Km) | RTS (KN) | Short Circuit (KA s) | |
| OPGW-191 [110.8,296.0] | 24 | 18.0 | 809 | 110.8 | 296.0 | |
| OPGW-146 [84.3,172.0] | 28 | 15.8 | 625 | 84.3 | 172.0 | |
| OPGW-146 [72.7,177.4] | 28 | 15.8 | 591 | 72.7 | 177.4 | |
| OPGW-199 [115.3,322.2] | 48 | 18.4 | 845 | 115.3 | 322.2 | |
| OPGW-226 [128.6,414.2] | 60 | 19.7 | 954 | 128.6 | 414.2 | |
