Tensile Strength
1/2"-13UNC = 7800lbs
5/8" - 11UNC = 13350lbs
3/4" - 10UNC = 20050lbs
Material: Hot dip galv Steel as per ASTM A123 & CSA G164
Manufactured per ASTM And CSA STDS
For Lock nut and cotter pin add suffix "BNLK" to part #
Add suffix "C" to part # for Charpy Level 1 Impact - Average minimum energy absorption of 20J when tested at -20 degrees C
Add suffix "C15" to part # for Charpy Level 1.5 Impact - Average minimum energy absorption of 27J when tested at -30 degrees C
| Catalog No. | Bolt Dia. | Length | Thread Length | Eye Dimensions | Approx. Ship Wt. Per Each | ||
| inch | inch | inch | |||||
| OEB1205 | 1/2 | 5 | 4 | ||||
| OEB1206 | 6 | 4 | 7/16 x 1-1/4 x 1-5/8 | 0.66 lbs | |||
| OEB1208 | 8 | 4 | 0.77 lbs | ||||
| OEB1210 | 10 | 6 | |||||
| OEB1212 | 12 | 6 | 7/16 x 1-1/4 x 1-5/8 | 1.00 lbs | |||
| OEB1214 | 14 | 6 | |||||
| OEB5805 | 5/8 | 5 | 4 | ||||
| OEB5806 | 6 | 4 | 7/16 x 1-1/4 x 1-5/8 | 1.00 lbs | |||
| OEB5808 | 8 | 4 | 1.04 lbs | ||||
| OEB5809 | 9 | 4 | 1.13 lbs | ||||
| OEB5810 | 10 | 6 | 1.22 lbs | ||||
| OEB5812 | 12 | 6 | 1.44 lbs | ||||
| OEB5814 | 14 | 6 | 4.16 lbs | ||||
| OEB5816 | 16 | 6 | 1.68 lbs | ||||
| OEB5818 | 18 | 6 | 2.08 lbs | ||||
| OEB5820 | 20 | 6 | 2.40 lbs | ||||
| OEB5822 | 22 | 6 | |||||
| OEB5824 | 24 | 6 | |||||
| OEB3406 | 3/4 | 6 | 4 | ||||
| OEB3408 | 8 | 4 | 5/8 x 1-1/2 x 2 | 1.80 lbs | |||
| OEB3410 | 10 | 4 | 2.00 lbs | ||||
| OEB3412 | 12 | 6 | 2.28 lbs | ||||
| OEB3414 | 14 | 6 | 2.48 lbs | ||||
| OEB3416 | 16 | 6 | 2.68 lbs | ||||
| OEB3418 | 18 | 6 | 3.14 lbs | ||||
| OEB3420 | 20 | 6 | 3.26 lbs | ||||
