Dual Mounting Offset Extension Bracket
Single Mounting Single L Bracket Mounting
Bracket-Aluminum 6061-T6
Fasteners-Galvanized Steel per ASTM A123
Ground Lug- Stainless steel
| Catalog Number | Type | Pole Offset-A | Mounting Bolt Spacing B | Equipment Bolt Spacing C | Approx. Ship Wt. Per Each |
| inch | inch | inch | lbs | ||
| PMA01133815316 | Single Mounting | 13-3/8" | 15-3/16" | N/A | 2.95 |
| PMA011818 | 18" | 18" | N/A | 4.85 | |
| PMAL01143815316 | Single L Bracket Mounting | 14-3/8" | 15-3/16" | 4-1/4" | 2.15 |
| PMAL011818 | 18" | 18" | 4-1/4" | 4.1 | |
| PMA02123815316 | Dual Mounting | 12-3/8" | 15-3/16" | 6" | 2.4 |
| PMA02123815316 | 12 3/8" | 15-3/16" | 6" | 2.4 | |
| PMA021718 | 17" | 18" | 10" | 4.3 | |
| PMAOFB6121878 | Offset Extension Bracket | 6-1/2" | 18-7/8" | N/A | 2.95 |
