Material: Hot-Dip Galvanized Steel Per ASTM A153 & CSA G164
CSA standard C83-96 item standard: C83.61-96
| Catalog No. | Anchor Size | Rod Size | Ultimate Soil-Anchor Hold. Strength.-Lbs. | |||
| Area Sq. | Class 5 | Class 6 | Class 7 | |||
| inch | inch | inch | lbs | lbs | lbs | |
| NWA043454 | 4 | 3/4x54 | 12.5 | 4500 | 300 | 1500 |
| NWA063466 | 6 | 3/4x66 | 28 | 6500 | 5000 | 2500 |
| NWA080166 | 8 | 1x66 | 50 | 11000 | 9000 | 6000 |
| NWA1011466 | 10 | 1-1/4x66 | 78 | 13000 | 10000 | 7000 |
| NWA1011496 | 10 | 1-1/4x96 | 78 | 13000 | 10000 | 7000 |
| NWA1511496 | 15 | 1-1/4x96 | 176 | 20000 | 17000 | 14000 |
