TYPICAL PARAMETERS:
| Single Layer | ||||||
| MVA Standard | Fiber Count(Max) | Diameter (mm) | Weight (Kg /Km) | RTS (KN) | Short Circuit (KA s) | |
| OPGW-81 [73.9,43.6] | 24 | 12.5 | 488 | 73.9 | 43.6 | |
| OPGW-86 [76.8,49.5] | 24 | 12.8 | 510 | 76.8 | 49.5 | |
| OPGW-103 [93.8,68.9] | 24 | 13.8 | 611 | 93.8 | 68.9 | |
| OPGW-85 [76.8,46.8] | 32 | 12.8 | 509 | 76.8 | 46.8 | |
| OPGW-85 [50.5,54.5] | 32 | 12.8 | 445 | 50.5 | 54.5 | |
| OPGW-112 [106.7,80.0] | 36 | 14.7 | 688 | 106.7 | 80.0 | |
| OPGW-112 [86.0,90.3] | 48 | 14.7 | 627 | 86.0 | 90.3 | |
| OPGW-112 [62.7,104.5] | 48 | 14.7 | 498 | 62.7 | 104.5 | |
| OPGW-122 [65.6,123.9] | 48 | 15.2 | 534 | 65.6 | 123.9 | |
| OPGW-132 [121.0,108.7] | 60 | 16.0 | 810 | 121.0 | 108.7 | |
| OPGW-132 [63.9,148.0] | 60 | 16.0 | 545 | 63.9 | 148.0 | |
| Double Layers | ||||||
| MVA Standard | Fiber Count (Max) | Diameter (mm) | Weight (Kg /Km) | RTS (KN) | Short Circuit (KA s) | |
| OPGW-174 [101.0,247.7] | 24 | 17.7 | 744 | 101.0 | 247.7 | |
| OPGW-244 [141.2,479.7] | 24 | 20.7 | 1030 | 141.2 | 479.7 | |
| OPGW-249 [147.0,501.4] | 48 | 21.1 | 1065 | 147.0 | 501.4 | |
| OPGW-207 [121.8,348.1] | 48 | 19.4 | 892 | 121.8 | 348.1 | |
| OPGW-233 [135.8,441.9] | 60 | 20.6 | 999 | 135.8 | 441.9 | |
