TYPICAL PARAMETERS:
| Double Layers | ||||||
| ZTT Standard | Fiber Count(Max) | Diameter (mm) | Weight (Kg /Km) | RTS (KN) | Short Circuit (KA s) | |
| OPGW - 89 [55.4,62.9] | 24 | 12.6 | 381 | 55.4 | 62.9 | |
| OPGW - 91 [53.6,66.4] | 24 | 12.7 | 377 | 53.6 | 66.4 | |
| OPGW - 110 [90.0,86.9] | 24 | 14.0 | 600 | 90.0 | 86.9 | |
| OPGW - 104 [64.6,85.6] | 28 | 13.6 | 441 | 64.6 | 85.6 | |
| OPGW- 127 [79.0,129.5] | 36 | 15.0 | 537 | 79.0 | 129.5 | |
| OPGW- 137 [85.0,148.5] | 36 | 15.6 | 575 | 85.0 | 148.5 | |
| OPGW- 145 [98.6,162.3] | 48 | 16.0 | 719 | 98.6 | 162.3 | |
| OPGW-164 [100.2,214.8] | 48 | 17.1 | 687 | 100.2 | 214.8 | |
| OPGW- 120 [70.0,117.6] | 72 | 15.0 | 509 | 70.0 | 117.6 | |
| OPGW- 137 [79.7,152.2] | 96 | 16.0 | 574 | 79.7 | 152.2 | |
| OPGW- 174 [98.6,146.5] | 128 | 18.2 | 724 | 98.6 | 246.5 | |
| Three Layers | ||||||
| ZTT Standard | Fiber Count(Max) | Diameter (mm) | Weight (Kg /Km) | RTS (KN) | Short Circuit (KA s) | |
| OPGW-232 [343.0,191.4] | 28 | 20.15 | 1696.0 | 343.0 | 191.4 | |
| OPGW-254 [116.5,554.6] | 36 | 21.0 | 889.0 | 116.5 | 554.6 | |
| OPGW-347 [366.9,687.7] | 48 | 24.7 | 2157.0 | 366.9 | 687.7 | |
| OPGW-282 [358.7,372.1] | 96 | 22.5 | 1938.0 | 358.7 | 372.1 | |
