Material: Hot-Dip Galvanized Steel Per ASTM A153 & CSA G164
SGS02GC SGS02PP SGS212GC SGS212PP
| SIDEWALK GUY STRUTS | ||||
| Catalog No. | Pipe Size | Description | Shipping Wt (100 pcs) | Std Pkg. |
| inch | lbs | |||
| SGS02GC | 2 | Guy clamp fitting | 300 | 15 |
| SGS02PP | 2 | Pole plate fitting | 200 | 15 |
| SGS212GC | 2 to 2-1/2 | Guy clamp fitting | 500 | 10 |
| SGS212PP | 2 to 2-1/2 | Pole plate fitting | 400 | 10 |
Fitting SideWalk Guy Deadend
SGDPE212 SGDSE21203
| Pole End Fitting | |||||
| Catalog No. | Accomodates Pipe Size | Mouting Holes | Approx. Ship Wt. Per Each (lbs) | ||
| SGDPE02 | 2" | One 11/16" & Two 9/16" | 4.55 | ||
| SGDPE212 | 2-1/2' | Two 9/16" | 3.66 | ||
| SGDPE2212 | 2" and 2-1/2" | Four 9/16" | 4.69 | ||
| Strand End Fitting | |||||
| Catalog No. | Accommodates | Number of Guy Wires | Minimum Guy Wire Size | Approx. Ship. Wt. Per Each (lbs) | |
| Pipe Size | |||||
| SGDSE201 | 2" | 1 | 5/16" | 4,95 | |
| SGDSE202 | 2 | 6,20 | |||
| SGDSE21203 | 2-1/2" | 3 | 3,93 | ||
