Material: Hot-Dip Galvanized Steel Per ASTM A153 & CSA G164
CSA Standard c83-96 item standard C83.24-96
| Catalog No. | Rod Diameter |
Rod Length |
Anchor Size |
Anchor Expanded |
Hole Size |
Weight |
| inch | inch | inch | inch | inch | lbs | |
| RAEX3415134 | 3/4'' | 15'' | 1-3/4'' | 2-3/8'' | 1-7/8'' | 5.00 |
| RAEX3430134 | 3/4'' | 30'' | 1-3/4'' | 2-3/8'' | 1-7/8'' | 6.71 |
| RAEX3453134 | 3/4'' | 53'' | 1-3/4'' | 2-3/8'' | 1-7/8'' | 9.72 |
| RAEX3460134 | 3/4'' | 60'' | 1-3/4'' | 2-3/8'' | 1-7/8'' | 10.50 |
| RAEX3472134 | 3/4'' | 72'' | 1-3/4'' | 2-3/8'' | 1-7/8'' | 12.00 |
| RAEX3484134 | 3/4'' | 84'' | 1-3/4'' | 2-3/8'' | 1-7/8'' | 13.60 |
| RAEX3496134 | 3/4'' | 96'' | 1-3/4'' | 2-3/8'' | 1-7/8'' | 15.00 |
| RAEX0130214 | 1'' | 30'' | 2-1/4'' | 3-1/8'' | 2-3/8'' | 13.85 |
| RAEX0153214 | 1'' | 53'' | 2-1/4'' | 3-1/8'' | 2-3/8'' | 18.27 |
| RAEX0172214 | 1'' | 72'' | 2-1/4'' | 3-1/8'' | 2-3/8'' | 23.76 |
| RAEX0196214 | 1'' | 96'' | 2-1/4'' | 3-1/8'' | 2-3/8'' | 28.94 |
