TYPICAL PARAMETERS:
| Single Layer | ||||||
| MVA Standard | Fiber Count(Max) | Diameter (mm) | Weight (Kg /Km) | RTS (KN) | Short Circuit (KA s) | |
| OPGW-32 [40.6,4.7] | 12 | 7.8 | 243 | 40.6 | 4.7 | |
| OPGW-42 [54.0,8.4] | 24 | 9 | 313 | 54.0 | 8.4 | |
| OPGW-42 [43.5,10.6] | 24 | 9.0 | 284 | 43.5 | 10.6 | |
| OPGW-54 [67.8,13.9] | 36 | 10.2 | 394 | 67.8 | 13.9 | |
| OPGW-54 [55.9,17.5] | 36 | 10.2 | 356 | 55.9 | 17.5 | |
| OPGW-61 [73.7,17.5] | 48 | 10.8 | 438 | 73.7 | 17.5 | |
| OPGW-61 [55.1,24.5] | 48 | 10.8 | 358 | 55.1 | 24.5 | |
| OPGW-68 [80.8,21.7] | 54 | 11.4 | 485 | 80.8 | 21.7 | |
| OPGW-75 [63.0,36.3] | 60 | 12.0 | 459 | 63.0 | 36.3 | |
| OPGW-76 [54.5,41.7] | 60 | 12.0 | 385 | 54.5 | 41.7 | |
| OPGW-79 [51.2,49.5] | 72 | 12.3 | 403 | 51.2 | 49.5 | |
| Double Layers | ||||||
| MVA Standard | Fiber Count(Max) | Diameter (mm) | Weight (Kg /Km) | RTS (KN) | Short Circuit (KA s) | |
| OPGW-96 [121.7,42.2] | 12 | 13.00 | 671 | 121.7 | 42.2 | |
| OPGW-127 [141.0,87.9] | 24 | 15.0 | 825 | 141.0 | 87.9 | |
| OPGW-127 [77.8,128.0] | 24 | 15.0 | 547 | 77.8 | 128.0 | |
| OPGW-145 [121.0,132.2] | 28 | 16.0 | 857 | 121.0 | 132.2 | |
| OPGW-163 [138.2,183.6] | 36 | 17.0 | 910 | 138.2 | 183.6 | |
| OPGW-163 [99.9,213.7] | 36 | 17.0 | 694 | 99.9 | 213.7 | |
| OPGW-183 [109.7,268.7] | 48 | 18.0 | 775 | 109.7 | 268.7 | |
| OPGW-183 [118.4,261.6] | 48 | 18.0 | 895 | 118.4 | 261.6 | |
