Material: Hot-Dip Galvanized Steel Per ASTM A153 & CSA G164
|
Catalog Number
|
Steel Size
|
Span - Length Hole to Hole-B
|
Drop-C
|
Length End to End-A
|
Hole Diameters |
Approx. Ship Wt. per Each
|
|
| Crossarm Mounting | Pole Mounting | ||||||
| inch | inch | inch | inch | inch | inch | lbs | |
| VB37112 |
1-1/2" x 1-1/2" x 3/16"
|
37 | 12 | 40 |
9/16
|
11/16
|
8.2 |
| VB42112 | 42 | 12 | 45 | ||||
| VB4811214 | 48 | 14 | 51 | 9.2 | |||
| VB4811218 | 48 | 18 | 51 | 9.8 | |||
| VB60112 | 60 | 18 | 63 | 11 | |||
| VB42134 |
1-3/4" x 1-3/4" x 3/16"
|
42 | 12 | 45 | 9/16 x 1 | 8.2 | |
| VB60134 | 60 | 18 | 63 | 9/16 x 1 | 11.2 | ||
| VB72134 | 72 | 22 | 75 | 9/16 | 16 | ||
